How to Build a Vision-Guided Web AI Agent with MolmoWeb-4B Using Multimodal Reasoning and Action Prediction

def parse_click_coords(action_str):
   """
   Extract normalised (x, y) coordinates from a click action string.
   e.g., 'click(0.45, 0.32)' -> (0.45, 0.32)
   Returns None if the action is not a click.
   """
   match = re.search(r"click\(\s*([\d.]+)\s*,\s*([\d.]+)\s*\)", action_str)
   if match:
       return float(match.group(1)), float(match.group(2))
   return None




def parse_action_details(action_str):
   """
   Parse a MolmoWeb action string into a structured dict.
   Returns:  {"type": "click", "x": 0.45, "y": 0.32}
             {"type": "goto", "url": "https://..."}
             {"type": "type", "text": "query text"}
             {"type": "scroll", "direction": "down"}
             {"type": "press", "key": "Enter"}
             {"type": "send_msg", "message": "The answer is ..."}
             {"type": "unknown", "raw": "..."}
   """
   action_str = action_str.strip()


   m = re.match(r'click\(\s*([\d.]+)\s*,\s*([\d.]+)\s*\)', action_str)
   if m:
       return {"type": "click", "x": float(m.group(1)), "y": float(m.group(2))}


   m = re.match(r'goto\(\s*["\'](.+?)["\']\s*\)', action_str)
   if m:
       return {"type": "goto", "url": m.group(1)}


   m = re.match(r'type\(\s*["\'](.+?)["\']\s*\)', action_str)
   if m:
       return {"type": "type", "text": m.group(1)}


   m = re.match(r'scroll\(\s*["\']?(up|down)["\']?\s*\)', action_str)
   if m:
       return {"type": "scroll", "direction": m.group(1)}


   m = re.match(r'press\(\s*["\'](.+?)["\']\s*\)', action_str)
   if m:
       return {"type": "press", "key": m.group(1)}


   m = re.match(r'send_msg\(\s*["\'](.+?)["\']\s*\)', action_str, re.DOTALL)
   if m:
       return {"type": "send_msg", "message": m.group(1)}


   m = re.match(r'(new_tab|go_back|switch_tab)\(\s*(\d*)\s*\)', action_str)
   if m:
       result = {"type": m.group(1)}
       if m.group(2):
           result["tab"] = int(m.group(2))
       return result


   return {"type": "unknown", "raw": action_str}




def visualise_click(image, action_str, title="MolmoWeb Prediction"):
   """
   Draw the predicted click location on the screenshot and display it.
   Coordinates are normalised (0-1); we convert to pixel space.
   """
   coords = parse_click_coords(action_str)


   fig, ax = plt.subplots(1, 1, figsize=(12, 7))
   ax.imshow(image)
   ax.set_title(title, fontsize=14)


   if coords:
       x_norm, y_norm = coords
       w, h = image.size
       x_px, y_px = x_norm * w, y_norm * h


       circle = patches.Circle(
           (x_px, y_px), radius=18, linewidth=3,
           edgecolor="red", facecolor="none"
       )
       ax.add_patch(circle)
       ax.plot(x_px, y_px, "r+", markersize=20, markeredgewidth=3)


       ax.annotate(
           f"click({x_norm:.3f}, {y_norm:.3f})",
           (x_px, y_px), xytext=(x_px + 25, y_px - 25),
           fontsize=11, color="white",
           bbox=dict(boxstyle="round,pad=0.3", facecolor="red", alpha=0.8),
           arrowprops=dict(arrowstyle="->", color="red", lw=2),
       )
   else:
       ax.text(
           0.5, 0.02, f"Action: {action_str}", transform=ax.transAxes,
           fontsize=12, ha="center", color="white",
           bbox=dict(boxstyle="round,pad=0.4", facecolor="blue", alpha=0.8),
       )


   ax.axis("off")
   plt.tight_layout()
   plt.show()




def download_image(url, size=(1280, 720)):
   """Download an image from a URL and resize to browser viewport dimensions."""
   response = requests.get(url, timeout=15)
   img = Image.open(BytesIO(response.content)).convert("RGB")
   img = img.resize(size, Image.LANCZOS)
   return img




def create_synthetic_webpage(title="Example Page", elements=None):
   """
   Create a synthetic webpage screenshot for testing.
   'elements' is a list of dicts: {"type": "button"|"input"|"text"|"link",
                                    "text": str, "pos": (x, y)}
   """
   img = Image.new("RGB", (1280, 720), color=(255, 255, 255))
   draw = ImageDraw.Draw(img)


   draw.rectangle([0, 0, 1280, 50], fill=(240, 240, 240))
   draw.rectangle([180, 10, 900, 40], outline=(200, 200, 200), width=1, fill="white")
   draw.text((200, 16), f"https://www.example.com", fill=(100, 100, 100))


   for cx in [30, 60, 90]:
       draw.ellipse([cx - 8, 17, cx + 8, 33], fill=(200, 200, 200))


   draw.text((50, 70), title, fill="black")


   if elements:
       for el in elements:
           x, y = el["pos"]
           if el["type"] == "button":
               draw.rectangle([x, y, x + 150, y + 35], fill=(66, 133, 244))
               draw.text((x + 10, y + 8), el["text"], fill="white")
           elif el["type"] == "input":
               draw.rectangle([x, y, x + 300, y + 35], outline=(180, 180, 180), width=2)
               draw.text((x + 10, y + 8), el["text"], fill=(150, 150, 150))
           elif el["type"] == "text":
               draw.text((x, y), el["text"], fill="black")
           elif el["type"] == "link":
               draw.text((x, y), el["text"], fill=(66, 133, 244))


   return img




print("Helper functions defined successfully.")




print("\n" + "=" * 70)
print("SECTION 5: Single-step inference - blank page (cold start)")
print("=" * 70)
print("The agent starts at about:blank and must decide its first action.\n")


blank_image = Image.new("RGB", (1280, 720), color="white")


task = "Go to arxiv.org and find the latest paper about Molmo from Ai2"


prompt = build_prompt(
   task_description=task,
   page_url="about:blank",
   page_index=0,
)


print(f"Task: {task}")
print("Screenshot: blank white image (about:blank)")
print("Running inference...\n")


raw_output = run_inference(prompt, blank_image)


print(f"Raw model output:\n{raw_output}\n")


parsed = parse_thought_and_action(raw_output)
print(f"Thought: {parsed['thought']}")
print(f"Action:  {parsed['action']}")


action_details = parse_action_details(parsed["action"])
print(f"Parsed:  {action_details}")
