The Dirichlet Process Mixture Model

This blog post is the fourth part of the series on Clustering with Dirichlet Process Mixture Models. In previous articles we discussed the Finite Dirichlet Mixture Models and we took the limit of their model for infinite k clusters which led us to the introduction of Dirichlet Processes. As we saw, our target is to build a mixture model which does not require us to specify the number of k clusters/components from the beginning. After presenting different representations of Dirichlet Processes, it is now time to actually use DPs to construct an infinite Mixture Model that enable us to perform clustering. The target of this article is to define the Dirichlet Process Mixture Models and discuss the use of Chinese Restaurant Process and Gibbs Sampling. If you have not read the previous posts, it is highly recommended to do so as the topic is a bit theoretical and requires good understanding on the construction of the model.

Update: The Datumbox Machine Learning Framework is now open-source and free to download. Check out the package com.datumbox.framework.machinelearning.clustering to see the implementation of Dirichlet Process Mixture Models in Java.

1. Definition of Dirichlet Process Mixture Model

Using Dirichlet Processes allows us to have a mixture model with infinite components which can be thought as taking the limit of the finite model for k to infinity. Let’s assume that we have the following model:

Equation 1: Dirichlet Process Mixture Model

Where G is defined as and used as a short notation for which is a delta function that takes 1 if and 0 elsewhere. The θ_i are the cluster parameters which are sampled from G. The generative distribution F is configured by cluster parameters θ_i and is used to generate x_i observations. Finally we can define a Density distribution which is our mixture distribution (countable infinite mixture) with mixing proportions and mixing components .

Figure 1: Graphical Model of Dirichlet Process Mixture Model

Above we can see the equivalent Graphical Model of the DPMM. The G₀ is the base distribution of DP and it is usually selected to be conjugate prior to our generative distribution F in order to make the computations easier and make use of the appealing mathematical properties. The α is the scalar hyperparameter of Dirichlet Process and affects the number of clusters that we will get. The larger the value of α, the more the clusters; the smaller the α the fewer clusters. We should note that the value of α expresses the strength of believe in G₀. A large value indicates that most of the samples will be distinct and have values concentrated on G₀. The G is a random distribution over Θ parameter space sampled from the DP which assigns probabilities to the parameters. The θ_i is a parameter vector which is drawn from the G distribution and contains the parameters of the cluster, F distribution is parameterized by θ_i and x_i is the data point generated by the Generative Distribution F.

It is important to note that the θ_i are elements of the Θ parameter space and they “configure” our clusters. They can also be seen as latent variables on x_i which tell us from which component/cluster the x_i comes from and what are the parameters of this component. Thus for every x_i that we observe, we draw a θ_i from the G distribution. With every draw the distribution changes depending on the previous selections. As we saw in the Blackwell-MacQueen urn scheme the G distribution can be integrated out and our future selections of θ_i depend only on G₀: . Estimating the parameters θi from the previous formula is not always feasible because many implementations (such as Chinese Restaurant Process) involve the enumerating through the exponentially increasing k components. Thus approximate computational methods are used such as Gibbs Sampling. Finally we should note that even though the k clusters are infinite, the number of active clusters is . Thus the θ_i will repeat and exhibit a clustering effect.

2. Using the Chinese Restaurant Process to define an Infinite Mixture Model

The model defined in the previous segment is mathematically solid, nevertheless it has a major drawback: for every new x_i that we observe, we must sample a new θ_i taking into account the previous values of θ. The problem is that in many cases, sampling these parameters can be a difficult and computationally expensive task.

An alternative approach is to use the Chinese Restaurant Process to model the latent variables z_i of cluster assignments. This way instead of using θ_i to denote both the cluster parameters and the cluster assignments, we use the latent variable z_i to indicate the cluster id and then use this value to assign the cluster parameters. As a result, we no longer need to sample a θ every time we get a new observation, but instead we get the cluster assignment by sampling z_i from CRP. With this scheme a new θ is sampled only when we need to create a new cluster. Below we present the model of this approach:

Equation 2: Mixture Model with CRP

The above is a generative model that describes how the data x_i and the clusters are generated. To perform the cluster analysis we must use the observations x_i and estimate the cluster assignments z_i.

3. Mixture Model Inference and Gibbs Sampling

Unfortunately since Dirichlet Processes are non-parametric, we can’t use EM algorithm to estimate the latent variables which store the cluster assignments. In order to estimate the assignments we will use the Collapsed Gibbs Sampling.

The Collapsed Gibbs Sampling is a simple Markov Chain Monte Carlo (MCMC) algorithm. It is fast and enables us to integrate out some variables while sampling another variable. Nevertheless this algorithms requires us to select a G₀ which is a conjugate prior of F generative distribution in order to be able to solve analytically the equations and be able to sample directly from .

The steps of the Collapsed Gibbs Sampling that we will use to estimate the cluster assignments are the following:

• Initialize the z_i cluster assignments randomly
• Repeat until convergence
• Select randomly a x_i

• Keep the other z_j fixed for every j≠i:
• Assign a new value on z_i by calculating the “CRP probability” that depends on z_j and x_j of all j≠i:

In the next article we will focus on how to perform cluster analysis by using Dirichlet Process Mixture models. We will define two different Dirichlet Process Mixture Models which use the Chinese Restaurant Process and the Collapsed Gibbs Sampling in order to perform clustering on continuous datasets and documents.
